Signal Isolation Transformer

Name: Signal Isolation Transformer
SKU: TSM-ISO
Price: 67.92 USD
Availability: InStock

$67.92 MSRP

Model TSM-ISO

Eliminates ground loops and DC paths, reducing hum and noise sometimes caused by connecting different pieces of audio equipment in a system. The 1:1 transformer winding ratio (600 ohm primary, 600 ohm secondary) provides negligible insertion loss between input and output.

Add to Favorites

Compare

Blocks ground loops and DC paths
No physical connection between input and output
Passes only audio signals
Handles signal levels up to 200mW
Small chassis for convenient mounting
Direct replacement for standard 36 in. RCA cable
Chassis: 1.625 in. x 4.25 in. x 1.00 in.

Spec Sheet: 1247-TSMISO

The signal isolation transformer shall be Lowell Model TSM-ISO. It shall be capable of eliminating ground loops and DC paths between separate pieces of audio equipment. Connections to the transformer shall be made via male RCA connectors and shall be approximately 36 inches long. The thermoplastic housing shall have holes for mounting to any convenient surface.
