45U Relay Rack

Name: 45U Relay Rack
SKU: LRR-4515
Price: 474.96 USD
Availability: InStock

15"D x 20"W

$474.96 MSRP

Model LRR-4515

The two-post, open frame floor rack provides full access to mounted equipment, ideal for telecommunications, commercial sound, broadcast, data and switching applications. Made in the U.S.A. with aluminum top/base and 11-gauge steel vertical channels, the rack has a smooth black powder epoxy finish. Ships unassembled.

Add to Favorites

Compare

Steel channels tapped 10-32 (3 in. wide)
Two piece aluminum top and two piece base
Black finish
Four holes for anchors (not included)
Assembly and mounting hardware
Ships unassembled

Rack Space: 45U
Height: 84.00 in.
Width: 20.25 in.
Depth: 15.00 in.

Spec Sheet: 1561-LRR4515
CAD drawings: LRR-4515
Revit Models: LRR Series

EIA/TIA compliant
RoHS compliant
Certified U.S. steel
Made in U.S.A.

The relay rack shall be Lowell Model LRR-4515 which shall measure 20.25″W x 15″D (at base) x 84″H. It shall have 45 rack units of space. The rack shall have a smooth black powder epoxy finish. It shall ship unassembled and feature two (3″W) vertical channels of 11-gauge steel with mounting holes tapped 10-32 on E.I.A. mounting centers, a two-piece aluminum top, and a two-piece aluminum base with holes to secure to floor when specified by code. It shall include assembly and panel mounting hardware.

Cable Management
Hardware
Mounting Brackets for Power Strip: PCMB-6
Center-mount shelf: CMS Series
