Recessed Enclosure for 8 inch driver

Name: Recessed Enclosure for 8 inch driver
SKU: CP810
Price: 67.74 USD
Availability: InStock

For screw-mount grille

$67.74 MSRP

Model CP810

Enclosure with an extended grille mounting flange is for recessed installation, ideal for new construction where the flange can protect the opening from plaster, poured concrete or sheetrock. It can also be used in existing construction when installed in suspended tile ceilings. Steel with black powder epoxy finish.

Add to Favorites

Compare

Material: Welded heavy gauge unitized steel
Finish: Black
Diameter: 12.00 in.
Depth: 10.06 in.
Volume: 0.659 cu.ft.
Acoustic Treatment: 1.5″ thick acoustic batting
Mounting Aids: Knockouts, clips
For Grille Type: Screw-mount
Flange Type: Extended lip

Spec Sheet: 1282-CP810

Made in U.S.A.
Certified U.S. steel

The recessed enclosure for 8″ speakers shall be Lowell model CP810, which shall be welded unitized 22-gauge steel with black powder epoxy finish. It shall have a 12″ diameter with 10.06″ depth and feature an extended grille mounting flange, four combination knockouts (1/2″-3/4″) for conduit, four knockouts (1/2″) for wire, and 1.5″ thick acoustic lining. It shall be made in the U.S.A. with certified U.S. steel.

Screw-Mount Grilles: A8-AW, CS-8H, LO8-P, RS8-AW, WB-8
Drivers: 8 inch
Tile Bridge: LBS8-CP
